Use SIP to integrate with Cisco Unified Call Manager® and answer calls off-site
- ONVIF® Profile S Compliant
- Emergency call button
- ADA compliant raised lettering and Braille signage
- 802.3af PoE with PoE pass through (802.3at Type 2 PoE+)
- 1.23 megapixel fixed color video camera
- Camera vertical adjustment +15º, 0º, or -8º (manual)
- Capture and store the audio and video of active conversations on a microSD™ card (not provided by Aiphone)
- IP65 rated, weather resistant
- Stainless steel faceplate
- 2 contact outputs
- 6 trigger inputs
- 3-year warranty!
Dimensions 11-11⁄16″ H x 7″ W
| Power Source |
PoE (802.3af class 0) |
| Power Draw |
5.28 Watts |
| Camera |
⅓” CMOS 1.23 megapixel |
| Min. illumination |
5 lux |
| Audio Codec |
G.711 (μ-law, A law), G.722 |
| Video Codec |
H.264/AVC, motion JPEG |
| Network Protocols |
IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, FTP, DHCP, NTP, DNS |
| Port Security |
IEEE 802.1X |
| Operating Temp |
-40° – 140°F (-40° – 60°C) |
| Ingress Protection |
IP65, IK07 |
| Impact Protection |
IK07 |
| Mounting |
Flush mounted with included back box, or surface mount with the SBX-IDVFRA Stainless Steel surface mount box. Also compatible with the WB-CA, WB-HA, WB-CE, and WB-HE Emergency wall boxes or modular towers. |
